| Series: | YY | Frame construction: | Rolled Steel |
| Frame size: | 48 | Enclosure : | TENV |
| Power output: | 0.25 – 0.5HP | Insulation Class : | F |
| Voltages: | 115/230V | Cooling method: | IC411 |
| Number of poles: | 4, 6 | Certificates: | CCC, CE |
| Ambient Temperature : | 40 °C | Mounting arrangements: | Rigid Base |
| Type | HP | RPM | FRAME | VOLTAGE | 230V FLA | OVER. LOAD | INS. CLASS | S.F | ENCL. | DUTY | WGT LB/KG |
| YYA4814S-1D | .25 | 1625 | 48 | 115/230 | 1.3 | AUTO | F | 1.0 | TENV | AIROVER | 18/8.2 |
| YY4814S-1 | .25 | 1 625 | 48 | 115/230 | 1.3 | AUTO | F | 1.0 | TENV | AIROVER | 18/8.2 |
| YYA4814S-1H3ABN | .25 | 1 625 | 48 | 115/230 | 1.3 | AUTO | F | 1.0 | TENV | AIROVER | 18/8.2 |
| YYA4816S-1D | .25 | 1 060 | 48 | 115/230 | 1.3 | AUTO | F | 1.0 | TENV | AIROVER | 21/9.5 |
| YYA4824S-1D | .33 | 1 625 | 48 | 115/230 | 1.8 | AUTO | F | 1.0 | TENV | AIROVER | 19/8.6 |
| YY4824S-1 | .33 | 1625 | 48 | 115/230 | 1.8 | AUTO | F | 1.0 | TENV | AIROVER | 19/8.6 |
| YYA4824S-1H3ABN | .33 | 1625 | 48 | 115/230 | 1.8 | AUTO | F | 1.0 | TENV | AIROVER | 19/8.6 |
| YYA4826S-1D | .33 | 1 075 | 48 | 115/230 | 1.9 | AUTO | F | 1.0 | TENV | AIROVER | 22/10.0 |
| YYA4834S-1D | .50 | 1 625 | 48 | 115/230 | 2.6 | AUTO | F | 1.0 | TENV | AIROVER | 22/10.0 |
| YY4834S-1 | .50 | 1 625 | 48 | 115/230 | 2.6 | AUTO | F | 1.0 | TENV | AIROVER | 22/10.0 |
| YYA4834S-1H3ABN | .50 | 1 625 | 48 | 115/230 | 2.6 | AUTO | F | 1.0 | TENV | AIROVER | 22/10.0 |
| YYA4836S-1D | .50 | 1 060 | 48 | 115/230 | 2.8 | AUTO | F | 1.0 | TENV | AIROVER | 25/11.4 |
| Mounting arms(each) 7 inch armfor 3 bracket models | |||||||||||
| Mounting arms(each) 12 inch armfor 3 bracket models | |||||||||||
