| Series: | YYM | Frame construction: | Stainless Steel |
| Frame size: | 48Y | Enclosure : | TEAO |
| Power output: | 0.25 – 0.5HP | Insulation Class : | F |
| Voltages: | 115V, | Cooling method: | IC411 |
| Number of poles: | 2, 4, 6 | Certificates: | CCC, CE |
| Ambient Temperature : | 40 °C | Mounting arrangements: | Round – Swing Arm |
| Type | HP | RPM | FRAME | VOLTAGE | FLA | OVER LOAD | S.F | INS. CLASS | ENCL. | DUTY | WGT LB/KG |
| YYM486A36 | 1/4 | 1075 | 48Y | 115 | 3.5 | AUTO | 1.0 | F | TEAO | CONT. | 18.7 / 8.4 |
| YYM484A4 | 1/4 | 1 725 | 48Y | 115 | 3.1 | AUTO | 1.0 | F | TEAO | CONT. | 17.6 / 7.9 |
| YYM482A2 | 1/4 | 3450 | 48Y | 115 | 2.8 | AUTO | 1.0 | F | TEAO | CONT. | 16.5 / 7.4 |
| YYM486A37 | 1/3 | 1075 | 48Y | 115 | 4.1 | AUTO | 1.0 | F | TEAO | CONT. | 21.6 / 9.8 |
| YYM484A5 | 1/3 | 1725 | 48Y | 115 | 3.8 | AUTO | 1.0 | F | TEAO | CONT. | 18.5 / 8.3 |
| YYM482A3 | 1/3 | 3450 | 48Y | 115 | 3.5 | AUTO | 1.0 | F | TEAO | CONT. | 18.2 / 8.2 |
| YYM486A38 | 1/2 | 1075 | 48Y | 115 | 5.8 | AUTO | 1.0 | F | TEAO | CONT. | 26.4 / 11.9 |
| YYM484A6 | 1/2 | 1 725 | 48Y | 115 | 5.4 | AUTO | 1.0 | F | TEAO | CONT. | 21.2 / 9.6 |
| YYM482A4 | 1/2 | 3450 | 48Y | 115 | 5.2 | AUTO | 1.0 | F | TEAO | CONT. | 20.5 / 9.3 |
