| Series: | YCYN | Frame construction: | Rolled Steel |
| Frame size: | 56C | Enclosure : | TEFC |
| Power output: | 1 – 4HP | Insulation Class : | F |
| Voltages: | 115V, | Cooling method: | IC411 |
| Number of poles: | 4 | Certificates: | CCC, CE |
| Ambient Temperature : | 40 °C | Mounting arrangements: | Resilient Base |
| Type | HP | RPM | FRAME | VOLTAGE | FLA | OVER LOAD | S.F | INS. CLASS | ENCL. | DUTY | WGT LB/KG |
| YCYN5652D-* | 1.0 | 3450 | 56C | 230 | 6.0 | NONE | 1.0 | F | TEFC | CONT. | 27.5 / 12.4 |
| YCYN5652D-1 | 1.5 | 3450 | 56C | 230 | 8.8 | NONE | 1.0 | F | TEFC | CONT. | 31.9 / 14.4 |
| YCYGL8052 | 2 | 2850 | 56C | 230 | 10.8 | NONE | 1.0 | F | TEFC | CONT. | 48 / 21.7 |
| YCYN5692D-3 | 3 | 3450 | 56C | 230 | 12.8 | NONE | 1.0 | F | TEFC | CONT. | 48 / 21.7 |
| YCYN5692D-24 | 4 | 3450 | 56C | 230 | 16.5 | NONE | 1.0 | F | TEFC | CONT. | 52.4 / 23.7 |
