| Series: | YC, YS | Frame construction: | Rolled Steel |
| Frame size: | S56J, 56J | Enclosure : | ODP |
| Power output: | 0.5 – 3HP | Insulation Class : | F |
| Voltages: | 115/208-230V, 208-230/460 | Cooling method: | IC411 |
| Number of poles: | 2 | Certificates: | CCC, CE |
| Ambient Temperature : | 40 °C | Mounting arrangements: | Rigid Base |
| Type | HP | RPM | FRAME | VOLTAGE | 230V FLA | OVER LOAD | INS. CLASS | S.F | IP | DUTY | WGT LB/KG |
| YC4822D-J1H | .50 | 3600 | S56J | 115/208-230 | 4 | AUTO. | F | 1.6 | 20 | CONT. | 19/8.3 |
| YS4812D-J1H | .50 | 3600 | S56J | 208-230/460 | 0.7 | NONE | F | 1.6 | 20 | CONT. | 18/8.1 |
| YC4852D-J1H | .75 | 3600 | S56J | 1 1 5/208-230 | 4.5 | AUTO. | F | 1.5 | 20 | CONT. | 24/10.9 |
| YS4832D-J1H | .75 | 3600 | S56J | 208-230/460 | 1.1 | NONE | F | 1.5 | 20 | CONT. | 28/12.7 |
| YC4862D-J1H | 1.0 | 3600 | S56J | 1 1 5/208-230 | 5.9 | AUTO. | F | 1.4 | 20 | CONT. | 31/14.1 |
| YS4852D-J1H | 1.0 | 3600 | S56J | 208-230/460 | 1.5 | NONE | F | 1.4 | 20 | CONT. | 33/15.0 |
| YCN5652D-J1H | 1.5 | 3600 | 56J | 115/208-230 | 8.2 | AUTO. | F | 1.3 | 20 | CONT. | 32/14.5 |
| YSN5642D-J1H | 1.5 | 3600 | 56J | 208-230/460 | 2 | NONE | F | 1.3 | 20 | CONT. | 30/13.6 |
| YCYN5672D-J1H | 2.0 | 3600 | 56J | 1 1 5/208-230 | 8.6 | AUTO. | F | 1.2 | 20 | CONT. | 40/18.2 |
| YSN5652D-J1H | 2.0 | 3600 | 56J | 208-230/460 | 2.6 | NONE | F | 1.2 | 20 | CONT. | 35/15.9 |
| YCYN5692D-J1H | 3.0 | 3600 | 56J | 230 | 11.8 | AUTO. | F | 1.15 | 20 | CONT. | 49/22.2 |
| YSN5682D-J1H | 3.0 | 3600 | 56J | 208-230/460 | 3.8 | NONE | F | 1.15 | 20 | CONT. | 42/19.1 |
