| Series: | YUM | Frame construction: | Rolled Steel |
| Frame size: | 48Y | Enclosure : | ODP |
| Power output: | 1/6 – 3/4HP | Insulation Class : | B |
| Voltages: | 115V, 115/208-230V | Cooling method: | IC411 |
| Number of poles: | 4 | Certificates: | CCC, CE |
| Ambient Temperature : | 40 °C | Mounting arrangements: | Resilient Base |
| Type | HP | RPM | FRAME | VOLTAGE | FLA | OVER LOAD | S.F | INS. CLASS | ENCL. | SPEED | WGT LB/KG |
| YUM484D4 | 1/6 | 1725 | 48Y | 115 | 3.6 | AUTO | 1.35 | B | ODP | 1 | 13.7/6.2 |
| YUM484D13 | 1725 | 48Y | 115/208-230 | 3.6/1.6-1.8 | AUTO | 1 .35 | B | ODP | 1 | 13.7 / 6.2 | |
| YUM484D5 | 1/4 | 1725 | 48Y | 115 | 5 | AUTO | 1.35 | B | ODP | 1 | 14.3 / 6.5 |
| YUM484D25 | 1725 | 48Y | 115/208-230 | 4.6/2.2-2.3 | AUTO | 1 .35 | B | ODP | 1 | 14.3 / 6.5 | |
| YUM484D10 | 1/3 | 1725 | 48Y | 115 | 6.6 | AUTO | 1.35 | B | ODP | 1 | 15.2/6.9 |
| YUM484D18 | 1725 | 48Y | 115/208-230 | 6.6/3.0-3.3 | AUTO | 1 .35 | B | ODP | 1 | 15.2 / 6.9 | |
| YUM484D8 | 1/2 | 1725 | 48Y | 115 | 7.6 | AUTO | 1.25 | B | ODP | 1 | 21.1 / 9.6 |
| YUM484D22 | 1725 | 48Y | 115/208-230 | 7.6/3.7-3.8 | AUTO | 1 .25 | B | ODP | 1 | 21.1 / 9.6 | |
| YUM484D36 | 3/4 | 1725 | 48Y | 115 | 11.6 | AUTO | 1.25 | B | ODP | 1 | 23.3 / 10.6 |
| YUM484D23 | 1725 | 48Y | 115/208-230 | 11.6/5.9-5.8 | AUTO | 1 .25 | B | ODP | 1 | 23.3 / 10.6 |
