| Series: | swimming pool motor | Frame construction: | Rolled Steel |
| Frame size: | 56C, 56Y, 56J | Enclosure : | ODP |
| Power output: | 0.33 – 2HP | Insulation Class : | B |
| Voltages: | 208-230/460V | Cooling method: | IC411 |
| Number of poles: | 4 | Certificates: | CCC, CE |
| Ambient Temperature : | 40 °C | Mounting arrangements: | Rigid Base |
| Type | HP | RPM | FRAME | VOLTAGE | PH | HZ | OVER-LOAD | INS.CLASS | S.F | DUTY | WGT LB/KG |
| YCYN5624-1GW | 0.33 | 1725 | 56C | 115 | 1 | 60 | AUTO | F | 1.15 | CONT. | 12/26 |
| YCYN5624-1GWS | 0.33 | 1725 | s56Y | 115 | 1 | 60 | AUTO | F | 1.15 | CONT. | 12/26 |
| YCYN5634-1GW | 0.5 | 1725 | 56C | 115 | 1 | 60 | AUTO | F | 1.15 | CONT. | 13/29 |
| YCN5652D-J1H | 1.5 | 3450 | 56J | 115/208-230 | 1 | 60 | AUTO | F | 1.3 | CONT. | 14.5/32 |
| Type | HP | RPM | FRAME | VOLTAGE | PH | HZ | OVER-LOAD | INS.CLASS | S.F | DUTY | SPEED | WGT LB/KG |
| YYN5652-L7 | 1 | 3600 | 56Y | 115/208-230 | 1 | 60 | AUTO | F | 1.4 | CONT. | 1 | 15/33 |
| YYN5672-L7 | 1.5 | 3600 | 56Y | 115/208-230 | 1 | 60 | AUTO | F | 1.3 | CONT. | 1 | 18/40 |
| YYN5682-L7 | 2.0 | 3600 | 56Y | 208-230 | 1 | 60 | AUTO | F | 1.3 | CONT. | 1 | 19/42 |
| YYN5624O1 | 1.5 | 3450/1725 | 56Y | 230 | 1 | 60 | AUTO | F | 1.3 | CONT. | 2 | 18.6/41 |
| YYN5682-L8 | 2 | 3450/1725 | 56Y | 230 | 1 | 60 | AUTO | F | 1.3 | CONT. | 2 | 19.6/43 |
| YSN5672-L7 | 2/1.5 | 3600 | 56Y | 208-230/460,190/380 | 3 | 60/50 | AUTO | F | 1.15 | CONT. | 1 | 17.2/38 |
| YSN5692-L7 | 3/2.0 | 3600 | 56Y | 208-230/460,190/380 | 3 | 60/50 | AUTO | F | 1.15 | CONT. | 1 | 20.5/45 |
| Type | HP | RPM | FRAME | VOLTAGE | PH | HZ | OVER-LOAD | INS.CLASS | S.F | DUTY | WGT LB/KG |
| YYN5652-L7C | 1 | 3600 | 56J | 115/208-230 | 1 | 60 | AUTO | F | 1.4 | CONT | 15/33 |
| YYN5672-L7C | 1.5 | 3600 | 56J | 115/208-230 | 1 | 60 | AUTO | F | 1.3 | CONT | 18/18 |
| YYN5682-L7C | 2 | 3600 | 56J | 208-230 | 1 | 60 | AUTO | F | 1.3 | CONT | 19/42 |
| YCN5642K-JB | .75 | 3450 | 56J | 115/230 | 1 | 60 | AUTO | F | 1.1 | CONT | 14/31 |
