| Series: | YY | Frame construction: | Rolled Steel |
| Frame size: | 48 | Enclosure : | TENV |
| Power output: | 0.25 – 0.5HP | Insulation Class : | F |
| Voltages: | 115V/208-230V, 115V | Cooling method: | IC411 |
| Number of poles: | 4, 6 | Certificates: | CCC, CE |
| Ambient Temperature : | 40 °C | Mounting arrangements: | Round – Swing Arm |
| Type | HP | RPM | FRAME | VOLTAGE | 230V FLA | OVER LOAD | INS. CLASS | S.F | ENCL. | DUTY | WGT LB/KG |
| YYA4814A-2T | .25 | 1650 | 48 丫 | 115/208-230 | 1.3 | AUTO | F | 1.0 | TENV | AIROVER | 17/7.7 |
| YYA4814A-3T | .33 | 1650 | 48 丫 | 115/208-230 | 1.7 | AUTO | F | 1.0 | TENV | AIROVER | 20/9.1 |
| YYA4814A-3KT | .33 | 1650 | 48丫 | 115 | 3.4 (115V) | AUTO | F | 1.0 | TENV | AIROVER | 24/10.9 |
| YYA4836AMT | .33 | 1060 | 48 丫 | 115/208-230 | 1.5 | AUTO | F | 1.0 | TENV | AIROVER | 24/10.9 |
| YYA4814A-4T | .50 | 1650 | 48 丫 | 115/208-230 | 2.3 | AUTO | F | 1.0 | TENV | AIROVER | 22/10.0 |
| YYA4846AMT | .50 | 1060 | 48 丫 | 115/208-230 | 2.7 | AUTO | F | 1.0 | TENV | AIROVER | 26/11.8 |
